High Quality Bnc Male Connectors

FOB Reference Price:Get Latest Price
US $0.37-0.49 / Pieces | 500 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
RS
Model Number:
P/N: 01BTN3X001
Connector:
BNC plug
Frequency Range:
0~4GHz
VSWR(≤):
1.25
SupplyAbility
SupplyAbility:
300000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
50 pcs in a blister board, 50 sets in a carton. We also accept custom packing.
Port
Shenzhen
Lead Time :
7-21Days

We are Dongguan Runshun Technology CO.,ltd. We are factory ! It was founded in 2009. We are specialized in Antenna and connectors . We have cooperated with many companies in China and out of China( Intel, China Unicom, China Power Grid, Taoglas etc).
Antenna: Internal antenna , external antenna, WIFI antenna, GSM antenna, LTE antenna, GPS antenna, HDTV antenna etc..
Connectors: SMA, BNC, F, TNC, N, IEC, MCX, MMCX, FAKRA, SMB etc..
Features :
1. All materials comply with ROHS
2. High-wearing feature
3. White color: Anti-UV
4. Connector: 48H Salt Spray Test
5. OEM & ODM are both available.
6. Quality Assurance, 36 months warranty.
7. Riveting machine was invented by us.
8.We do lots of research and development in these area, if you meet any difficulties, feel free to contact us.



Specification

Connector

BNC Plug

Working frequency

0~3GHz

VSWR(≤)

1.25

Impedance(Ω)

50&75

Operating Temp(0C)

-65~ +165

Remarks



 BNC JK 6.pngBNC JK3.pngBNC JK5.pngBNC JK7.pngBNC JK11.pngBNC JKK.pngBNC K.pngBNC PJK.pngBNC-3.pngBNC-4.pngBNC-8.pngBNC-9.pngBNC-10.pngBNC-12.png
